Key Specifications/Special Features:
CPU
Operation system：Embedded Linux OS
Microcomputer processor：32Bit RSIC Embedded Processor
Video
Compression format：Motion-JPEG
Signal system：CMOS 300,000 pixel
Frame Rate：25fps PAL，30fps NTSC
Resolution：VGA(640*480), QVGA(320*240)
Video Adjustment：brightness, contrast, chroma, saturation.
minimum illumination：0.1 Lux/F1.2
S/N ratio：>48DB (AGC off)
shutter speed：1/50s(1/60s）-1/100，000s
white balance, backlight balance：auto
Lensstandard：6mm selected：3.6mm、8mm
Nightvision
Nightvision：Φ5 24 LED lights, if they are < 10Lux,Infrared light opens automatically,the nightvision distance is 20 m.
Network
Network interface：RJ-45，0/100Mb self-adaptable Ethernet slot
Protocol：TCP/IP、HTTP、ICMP、DHCP、FTP、SMTP、PPPoE etc.
Simultanious visitor：Support 5 direct visitors at the same time，but no limitation when using forwarder Server.
IP mode：Dynamic IP address,Static IP address,PPPOE
Other
Shape：Ceiling hemisphere, indoor use
Power：DC12V 1A
Temperature：-10~50 °C
Humidity：95% RH
size
item size: 142mm x95mm (D xH)
packaging size: 170mm x170mm x170mm (LxWxH)
weight
Net：505g
Gross: 800g ( Note: All products as per the material subjects.)
Attachment：Adaptor, CD（including introduction）, Manual, bracket
alarm
input/output：1/1
Intelligent Motion detection：Motion Detection setting
Alarm action：support email、message, etc. alarm
System
System requirement：Microsoft Win98 SE/ME/2000/XP、Vista, Internet Explorer 5.0, NET4.5 or above
Features
Security Settings：Supports two-level password: administrator authority, user authority
DDNS（free）：Free DDNS bounded
Superiority：P2P technology, mobile view
Center management software（free)：1,4,9,16,25,36 or 64 multiple video display optional in one screen, support record, alarm, remote playback on records and other management functions. |
