Specification |
| Operation System |
Embedded Linux |
| Main Processor |
Hisilicon 3518E,130MPixel,Or Hisilicon 3516E,200MPixel |
| Image Sensor |
1/3" Ultra low illumination CMOS sensor |
| Ircut |
Support |
| Lens interface type |
C/CS Interface |
| Lowest Illumination |
0.01Lux |
| Compression Standard |
Video compression algorithm |
Support H.264 Main profile and H.264 Baseline |
| Audio compression algorithm |
G.762/G.711 |
| Compressed transport stream |
32Kbps-6144Kbps,can be defined.The default is 2048Kbps |
| Maximum Image |
960P |
1280*960P |
| 1080P |
1280*1080P |
| Definition |
First stream:960P(1280*960) |
First stream:1080P(1280*1080) |
|
Second stream:VGA(640*480),
QVGA(320*240),configurable |
Second stream:960P(1280*960) |
JPEG rate:Q720P(640*352),
Q720P(320*176),Configurable
(Used for mobile phone monitoring) |
Second stream:VGA(640*480),
QVGA(320*240),Configurable |
| |
JPEG rate:Q720P(640*352),
Q720P(320*176),Configurable
(Used for mobile phone monitoring) |
| Video frame rate |
15fps(50Hz),15fps(60Hz):CBR/VBR,
Adjustable |
15fps(50Hz),15fps(60Hz):CBR/VBR,
Adjustable |
| Character overlay |
Support OSD name, time date information overlay |
| Image configuration |
Brightness, contrast, saturation, degree of exposure, up and down inversion, left and right images adjustment. |
| Network Function |
storage function |
Support Maximum 128G Micro SD card,Support regular video storage |
Motion detection
|
Can Support 4 individual detection areas,
sensitivity:1-100,is Configurable
|
| alarm and data transportation |
alarm and send email to appointed email box;alarm and transfer the picture and
video to the appointed FTP server. |
| Network protocols |
Support:TCP/IP,HTTP,TCP,ICMP,UDP,
ARP,IGMP,SMTP,FTP,DHCP,DNS,
DDNS,NTP,UPNP,RTSP |
| Interface protocol |
Support ONVIF2.0 protocol |
| Interface |
Audio input |
1 way input,support MIC input and linear input, need tail line to support |
| Audio output |
1 way output, support the earphone or amplifier, need tail line to support |
| Network Interface |
100Base-T/100Base-TX,Ethernet interface |
| WIFI 802.11b/g/n wireless Interface |
General
specification |
weight |
1.2Kg |
| dimension |
215*110*80MM |
| working temperature |
-20 Celsius degree~+50Celsius degree |
| humility |
10~95%Rh |
| power supply |
DC12V2A |
| power consumption |
3W at day;12W when night vision lights open |
