Solar Cameras SEIC002 Solar energy camera SEIC002 supports wifi and 3G/4G wireless network remote mobile monitoring, can be used in special places. support harddisk and TF card.
Technical parameter |
item |
Description |
Model |
SEIC002 |
4 G Surveillance a professional camera |
wired net port |
support mode |
4G: China Unicom, mobile, telecommunications, foreign customers to provide a standard custom |
limited LAN |
LAN*1 |
WIFI |
WIFI wireless AP |
support a 802.11 bs/g/n |
antenna |
Optional |
cover range |
180 meters at the open spaces |
Band information |
TDD-LTE |
Downlink rate 130Mbps, uplink rate 35Mbps |
Band38/39/40/41 |
FDD-LTE |
Downlink rate 130Mbps, uplink rate 50Mbps |
Band1/3 |
WCDMA |
Downlink rate 42Mbps, uplink rate 5.76Mbps |
B1/B8 |
TD-SCDMA |
Downlink rate 4.2Mbps, uplink rate 2.2Mbps |
Band34/39 |
GSM/GPRS/EDGE |
Downlink rate 236.8Kbps, uplink rate 236.8Kbps |
900/1800 |
SIM card and antenna |
SIM card/USIM card |
Standard 6 pin SIM card interface, SIM 3V/1.8V card |
antenna |
5dBi full frequency rod antenna (optional) |
key |
Reload |
A key to restore the factory settings |
indicator |
status indicator |
Power supply, WIFI, 2/3/4G, signal strength indicator, WAN port, LAN port |
temperature |
work temperature |
-20 ~+70 Degrees Celsius |
saving temperature |
-40 ~+75 Degrees Celsius |
degree of humidity |
Working humidity |
10%~90% |
Storage humidity |
5%~90% |
power supply |
voltage of power supply |
DC5V~12V |
Current consumption |
At the DC12V power supply, the average current is 150mA, the maximum is 385mA | |
|
|
|
|
|
|
|
|
|
