 09.Camera >> HD SDI CAMERAS >> SDI MINI box camera SMCB1080312137

  SDI MINI box camera SMCB1080312137
Product Name:SDI MINI box camera SMCB1080312137
Product S/N:12817105525
Specification:CCTV 1/3' PANASONIC FULL 2.0MP 1080P LENS 3.6MM HD SDI OSD MENU WDR SECURITY MINI SDI BOX CAMERA FOR
Product Feature:CCTV 1/3' PANASONIC FULL 2.0MP 1080P LENS 3.6MM HD SDI OSD MENU WDR SECURITY MINI SDI BOX CAMERA FOR
Product Class:09.Camera
Quality Rank:
Chat with us:Click to chat via msnClick to chat via skype
Email:Welcome to contact me for the CCTV power supply business!
    Product Description

Product overview2.0 Mega Pixel, Panasinic CMOS Sensor
1080p(1920x1080)@30/25fps
Support WDR,3D-DNR,DEFOG
OSD menu,Motion detection,Privacy Zone,HLC,BLC
Dual Output-Megapixel HD-SDI(BNC)&CVBS:1.0 Vp-p 750hm



Technical parameters

Model No.

SMCB1080312137

Image Sensor

2.0Mega Pixel, Panasonic CMOS Sensor

Effective pixels

1920(H) x 1080(V)

Scanning system

Progressive Scan

Minimum illumination

0.001 Lux

Lens

3MP 3.6mm Korea Lens

IR view distance

N/A

WDR (Long and Short exposure)

OFF/ON(Level Adjustable)

O.S.D

Built-in

3D-DNR (3D Digital Noise Reduction)

OFF/ON(LOW/MIDDLE/HIGH)

Sens-Up

OFF/ON

Motion Detection

OFF/ON

Privacy Zone

OFF/ON

HLC

OFF/ON

B.L.C. control

OFF/ON

Defog

OFF/ON

White balance

AWB/ATW/PUSH/MANUAL

A.G.C

HIGH / LOW

Electronic shutter Speed

AUTO/MANUAL/FLK

Video output

HD-SDI CVBS:1.0 Vp-p Composite Signal (75ohm)

Operation temperature

-10 - +50

Operation Humidity

Within 95% RH

Power supply

DC12V(+/-15%)

Power Consumption

100mA

1* SDI  Panasonic 1080P 2.0MP SDI MINI Camera
120USD
