Universal AC input/full range
Protection: Overload /Over voltage/Over temperature/Short circuit
LED power on indication
100% full load burn-in test
Built-in EMI filter
1 year warranty
MTBF＞50,000 hours
Weight：0.23kg/piece
24.5g/carton(NW)
26.5kg/carton(GW)
AC Input voltage range..............AC88V-264V
Input frequency.........................47~63Hz
AC inrush current.......................5A/115V, 30A/230V (cold start)
DC voltage adjustment range......+10%
Output rated power.................100W
Output voltage.........................12V/24V optional
Rise time..................................50ms@full load (typical)
Hold up time.............................20ms@full load (typical)
Operating temp. & humidity ........-20℃～+55℃, 20%～93%RH (non condensing)
Storage temp. & humidity ...........-40℃～+85℃,10%～95%RH (non condensing)
Cooling ......................................free air convention
Safety standards.........................GB4943, UL60950-1, EN60950-1
EMC standards............................GB9254, EN55022 CLASS A
Withstand voltage.......................I/P-O/P: 1.5KVAC/IMIN
I/P-FG: 1.5KVAC/IMIN
O/P-FG: 0.5KVAC /1MIN Dimension: 255*49*29mm
super power supply technology:
LLC+synchronous rectification;
two transistor forward+synchronous rectification.
temperature comparison:
Cheap power supply from other supplier:121 Celsius degree on full load.
Our power supply:58 Celsius degree on full load.
 |
